SMP ARCEX | AUDIO EXTENDER WITH CEC ARC ONLY

SMP ARCEX
AUDIO EXTENDER WITH CEC ARC ONLY

ARC Audio extender over Cat6A/6 cable. The ARCEX is a 90m digital audio extender that extends ARC up to 90m/295ft. to ARC capable audio devices. The units are powered via supplied USB power supplies. Power can be attained from display as the current draw of the TX device is about 1/3 of a Watt. RX current draw is 0.7W. CEC and all ARC formats are supported from display back to rack/AVR/ARC capable amplifier. The ARCEX can also operate as an optical to optical extender as well (S/PDIF). There is a switch on the TX portion that will switch the unit to optical mode. This will disable ARC mode. The optical does not output on the HDMI ARC. Cat5e may be used, but some loss of distance may occur. Features include 90m/295ft via ARC, 150m/495ft. via optical. Use your smart TV as your audio source where your amplifier or other ARC enabled audio device is remote. Supports all ARC audio formats. CEC Pass-Thru (TV remote can control volume). Powers via USB Micro and draws very little current so display USB ports can be used. USB power supplies included. Compact design for easy placement. 3-Year warranty.
